VAYINATO SOBO WP-1880F Aquarium Top Filter Instruction Manual

تعارف

This manual provides detailed instructions for the safe and efficient operation, installation, and maintenance of your VAYINATO SOBO WP-1880F Aquarium Top Filter. Please read this manual thoroughly before use and retain it for future reference.

حفاظتی ہدایات

• Always disconnect the power supply before performing any maintenance, cleaning, or installation procedures.
• Ensure the pump is fully submerged in water at all times during operation to prevent overheating and damage.
• Do not operate the filter if any part is damaged or if the power cord is frayed.
• This appliance is for indoor use only and is designed for aquarium use. Do not use it for other purposes.
• بچوں کی پہنچ سے دور رکھیں۔
• والیوم کو یقینی بنائیںtage specified on the product label matches your local power supply.

پیکیج کے مشمولات

پیکج کھولنے پر تصدیق کریں کہ تمام اجزاء موجود ہیں اور بغیر کسی نقصان کے:

• VAYINATO SOBO WP-1880F Top Filter Unit (Filter box and pump)
• پانی کی دکان پائپ
• Filter sponge (1 Free Feet Sponge)
• بڑھتے ہوئے لوازمات

وضاحتیں

سیٹ اپ کی ہدایات

1. ان پیک اجزاء: احتیاط سے پیکیجنگ سے تمام حصوں کو ہٹا دیں. کسی بھی نقصان کا معائنہ کریں۔
2. Assemble Filter Box: Place the filter sponge and any additional filter media (not included) into the filter box. The filter box is designed with ample space for various media.


   Image: The internal compartment of the filter box, designed to hold various filter media. Note that filter media is not included.

3. Attach Pump to Filter Box: Connect the submersible pump to the filter box. Ensure a secure fit.
4. ایکویریم میں پوزیشن: Place the filter box on the rim of your aquarium. The pump unit should be fully submerged inside the aquarium water.


   Image: The filter pump is shown correctly submerged in the aquarium water, connected to the top filter box which rests on the tank rim.
5. Connect Water Outlet: Attach the water outlet pipe to the pump. Position the outlet to direct filtered water back into the tank, promoting circulation.


   Image: Diagram illustrating the water flow from the filter outlet, showing how it enhances oxygenation and circulation within the aquarium.

6. ڈوبنے کو یقینی بنائیں: Double-check that the pump is completely underwater before plugging in the power cord.

آپریٹنگ ہدایات

1. پاور آن: Once the filter is correctly installed and the pump is fully submerged, plug the power cord into a suitable electrical outlet. The filter will begin operating, providing filtration, water circulation, and oxygen supply.


   Image: The VAYINATO SOBO WP-1880F Top Filter highlighting its three primary functions: filtration, water circulation, and oxygen supply.
2. مسلسل آپریشن: For optimal aquarium health, the filter should operate continuously.
3. پانی کے بہاؤ کی نگرانی کریں: Periodically check the water flow from the outlet to ensure it is consistent. Reduced flow may indicate a need for cleaning.

دیکھ بھال

Regular maintenance is crucial for the longevity and efficiency of your filter and the health of your aquarium.

1. پاور منقطع کریں: Always unplug the filter from the power outlet before any maintenance.
2. فلٹر سپنج صاف کریں: Remove the filter sponge from the filter box. Rinse it thoroughly with old aquarium water (from a water change) to preserve beneficial bacteria. Do not use tap water directly as chlorine can harm bacteria.


   Image: Demonstrates the process of cleaning the filter sponge by rinsing it under water.
3. Clean Impeller and Pump Housing: Carefully detach the pump from the filter box. Remove the impeller cover and the impeller. Clean any debris or buildup from the impeller and its housing using a small brush.
4. Clean Filter Box: Rinse the filter box and water outlet pipe to remove any accumulated sludge or debris.
5. دوبارہ جوڑنا: Reassemble all components in reverse order. Ensure all connections are secure.
6. تعدد: Perform cleaning every 2-4 weeks, or as needed based on water clarity and flow rate.

خرابی کا سراغ لگانا

وارنٹی اور سپورٹ

وارنٹی کی معلومات یا تکنیکی مدد کے لیے، براہ کرم اپنے خوردہ فروش یا مینوفیکچرر سے براہ راست رابطہ کریں۔ خریداری کے ثبوت کے طور پر اپنی خریداری کی رسید اپنے پاس رکھیں۔

Manufacturer: Kintons

اصل ملک: چین
