GMKtec EVO-X2 AI Mini PC صارف دستی

تعارف

This manual provides detailed instructions for setting up, operating, and maintaining your GMKtec EVO-X2 AI Mini PC. Please read this manual thoroughly before using the device to ensure proper functionality and longevity.

تصویر: سامنے کی طرف view of the GMKtec EVO-X2 AI Mini PC.

سیٹ اپ کی ہدایات

1 پیک کھولنا اور ابتدائی معائنہ

• پیکیجنگ سے تمام اجزاء کو احتیاط سے ہٹا دیں۔
• Verify that all items listed in the package contents are present.
• Inspect the Mini PC for any signs of physical damage.

2. پیری فیرلز کو جوڑنا

Connect your monitor(s), keyboard, mouse, and other necessary peripherals to the appropriate ports on the Mini PC.

تصویر: پیچھے view of the Mini PC, illustrating available ports for peripheral connections.

• ڈسپلے کنکشن: The EVO-X2 supports up to four displays with 8K resolution via HDMI 2.1 (8K@60Hz), DisplayPort 1.4 (4K@60Hz), and dual USB4 ports (40Gbps with PD3.0/DP1.4/Data). Use the appropriate cables for your monitors.
• USB آلات: اپنے کی بورڈ، ماؤس، اور دیگر USB آلات کو دستیاب USB پورٹس سے مربوط کریں۔
• نیٹ ورک کنکشن: For wired internet, connect an Ethernet cable to the 2.5GbE LAN port. For wireless internet, ensure the Wi-Fi antennas are properly connected (if external) or that the internal Wi-Fi 7 module is enabled.

Image: The Mini PC connected to multiple displays, showcasing its 8K quad-screen capability.

3. پاور کنکشن

پاور اڈاپٹر کو Mini PC پر DC-in پورٹ سے جوڑیں، پھر پاور کورڈ کو وال آؤٹ لیٹ میں لگائیں۔

4. پاورنگ آن۔

Press the power button located on the front of the Mini PC. The system will boot up, and the operating system (Windows 11 Pro) will load. Follow the on-screen instructions for initial Windows setup if this is the first time using the device.

آپریٹنگ ہدایات

1. عام استعمال

The GMKtec EVO-X2 is designed for a wide range of tasks, from daily computing to demanding AI workloads and gaming. Its AMD Ryzen AI Max+ 395 processor with 16 Zen 5 cores and 32 threads provides robust performance.

2. AI Performance with XDNA 2 NPU

The integrated XDNA 2 NPU delivers over 50 TOPS of AI performance, making the EVO-X2 suitable for local AI tasks such as running large language models (LLMs) with applications like LM Studio. This allows for efficient AI processing without requiring cloud services.

Image: Visual representation of the XDNA 2 NPU architecture and its support for various AI applications.

3. Gaming with AMD Radeon 8090S iGPU

Equipped with an AMD Radeon 8090S iGPU featuring 40 compute units and RDNA 3.5 architecture, the Mini PC offers strong gaming performance, comparable to dedicated laptop GPUs. It supports Full HD gaming with high detail settings. The 96GB LPDDR5X memory also aids in running demanding applications and LLMs.

تصویر: تفصیلی view of the integrated AMD Radeon 8060S graphics, highlighting its gaming capabilities.

4. High-Speed Connectivity

• Wi-Fi 7 (802.11be): Provides wireless speeds up to 46 Gbps, significantly faster than previous Wi-Fi standards, ensuring stable and high-bandwidth connections.
• 2.5GbE LAN: The 2.5 Gigabit Ethernet port offers high-speed wired networking, suitable for applications requiring stable and fast data transfer, such as NAS or software routers.
• بلوٹوتھ 5.4: For reliable connections to wireless peripherals like headphones, keyboards, and mice.
• USB4: Dual USB4 ports offer 40Gbps data transfer, Power Delivery 3.0, and DisplayPort 1.4 capabilities.

Image: A comparison of Wi-Fi standards, emphasizing the speed benefits of Wi-Fi 7 on the Mini PC.

Image: The Mini PC connected via 2.5GbE Ethernet, illustrating high-speed network capabilities.

دیکھ بھال

1. کولنگ سسٹم

The EVO-X2 features a triple cooling system with two CPU turbo fans and a dedicated DDR5/SSD fan, along with three heat pipes and 360° airflow. This system is designed for efficient heat dissipation while maintaining a quiet operation (as low as 35 dB in silent mode).

• Ensure proper ventilation around the Mini PC. Do not block air vents.
• Periodically clean dust from the exterior vents using compressed air to maintain optimal cooling performance.

Image: Internal components of the Mini PC, showing the advanced cooling solution.

2. سافٹ ویئر اپڈیٹس

Regularly update your operating system (Windows 11 Pro) and drivers to ensure system stability, security, and optimal performance.

3. صفائی

Use a soft, dry cloth to clean the exterior of the Mini PC. Avoid using liquid cleaners directly on the device.

خرابی کا سراغ لگانا

• کوئی طاقت نہیں: یقینی بنائیں کہ پاور اڈاپٹر منی پی سی اور ورکنگ پاور آؤٹ لیٹ دونوں سے محفوظ طریقے سے جڑا ہوا ہے۔ اگر ضروری ہو تو ایک مختلف آؤٹ لیٹ آزمائیں۔
• کوئی ڈسپلے نہیں: Verify that the monitor is powered on and correctly connected to the Mini PC. Try different display cables or ports. Ensure the correct input source is selected on your monitor.
• کوئی انٹرنیٹ کنکشن نہیں: For wired connections, check the Ethernet cable and router status. For Wi-Fi, ensure Wi-Fi is enabled in Windows settings and that you are connected to the correct network with the correct password.
• سسٹم کی سست روی: Check for background applications consuming resources. Ensure sufficient free space on the SSD. Consider running system diagnostics or updating drivers.
• زیادہ گرم ہونا: Ensure the Mini PC has adequate ventilation and that air vents are not obstructed. Clean any dust accumulation.

تکنیکی وضاحتیں

وارنٹی اور سپورٹ

For warranty information and technical support, please refer to the following resources:

• ایمیزون سپورٹ: For inquiries related to your purchase, log in to your Amazon account, navigate to "Your Account" -> "Your Orders," and select "Ask Product Question" for the GMKtec EVO-X2.
• فروخت کے بعد سپورٹ: Contact the GMKtec After-Sales Team directly via email at eu-cs@gmktec.com 24/7 کسٹمر سپورٹ کے لیے۔

Image: Warranty and support contact information for GMKtec products.
