تعارف
This manual provides detailed instructions for the installation, operation, and maintenance of your SENSEA ICONE Hydromassage Shower Column. Please read this manual thoroughly before installation and use to ensure proper function and longevity of the product. Retain this manual for future reference.

شکل 1: مجموعی طور پر view of the SENSEA ICONE Hydromassage Shower Column, showcasing its sleek design and integrated controls.
مصنوعات کی خصوصیات
- پائیدار تعمیر: Made from aluminum, metal, stainless steel, and ABS for strength and impact resistance.
- Multiple Spray Functions: Features a handheld shower, two wall-mounted body jets, an overhead shower, and a waterfall function.
- آسان صفائی: Shower heads are equipped with anti-limescale points for simplified maintenance.
- مکمل نظام: Includes a shower panel with integrated faucets, a square overhead shower, a stainless steel hose, and a handheld shower.
سیٹ اپ اور انسٹالیشن
The SENSEA ICONE Hydromassage Shower Column is designed for wall mounting. Professional installation is recommended to ensure correct and secure fitting.
مطلوبہ اوزار (شامل نہیں):
- ڈرل
- پیمائش کرنے والا ٹیپ
- سطح
- پنسل
- سایڈست رنچ
- سیلانٹ ٹیپ (PTFE ٹیپ)
تنصیب کے مراحل:
- دیوار تیار کریں: Ensure the installation area is clean, dry, and structurally sound. Turn off the main water supply.
- نشان بڑھتے ہوئے پوائنٹس: Use the provided mounting template (if applicable) or measure and mark the drilling points on the wall according to the technical drawing. Ensure the marks are level.
- سوراخ ڈرل: Drill holes at the marked points using an appropriate drill bit for your wall type. Insert wall plugs if necessary.
- ماؤنٹ بریکٹ: Secure the mounting brackets to the wall using screws.
- پانی کی نلیوں کو جوڑیں: Connect the hot and cold water supply lines to the corresponding inlets on the back of the shower column. Ensure all connections are tight and sealed with PTFE tape to prevent leaks. Verify that the supplied hoses are of adequate length for your plumbing connections; longer hoses may be required in some installations.
- Hang Shower Column: Carefully hang the shower column onto the wall brackets, ensuring it is securely seated.
- حتمی رابطے: Connect the handheld shower hose to its outlet on the column.
- لیک کے لیے ٹیسٹ: Turn on the main water supply slowly and check all connections for leaks.

Figure 2: Technical drawing illustrating the dimensions and mounting points of the SENSEA ICONE Hydromassage Shower Column for installation planning.
آپریٹنگ ہدایات
The SENSEA ICONE Hydromassage Shower Column offers various water functions controlled by the integrated knobs.
کنٹرولز:
- درجہ حرارت کنٹرول نوب: Adjusts the water temperature. Turn clockwise for colder water, counter-clockwise for warmer water.
- فنکشن سلیکٹر نوب: Selects the desired water outlet. Rotate to switch between the overhead shower, waterfall, body jets, and handheld shower.
Shower Functions:
- Overhead Shower: Provides a wide, rain-like spray for a full body rinse.
- Waterfall Function: Delivers a broad, gentle sheet of water, ideal for a relaxing experience.
- باڈی جیٹس: Two sets of integrated jets provide a massaging spray for targeted relief.
- ہینڈ ہیلڈ شاور: Offers a focused spray, suitable for rinsing specific areas or cleaning the shower area.

Figure 3: Close-up of the overhead showerhead, illustrating the rain spray nozzles.

Figure 4: The waterfall function of the shower column, providing a broad, gentle flow of water.

Figure 5: Image showing the integrated body massage jets delivering a powerful, invigorating spray.

Figure 6: Close-up of the handheld showerhead in operation, demonstrating its focused spray pattern.
دیکھ بھال اور دیکھ بھال
Regular cleaning and maintenance will help preserve the appearance and functionality of your shower column.
صفائی:
- Use a soft cloth and mild soap or a non-abrasive bathroom cleaner.
- Avoid abrasive cleaners, scouring pads, or harsh chemicals, as these can damage the chrome finish and surfaces.
- The shower heads feature anti-limescale points. To remove limescale buildup, gently rub the rubber nozzles with your finger or a soft brush.
- صفائی کے بعد صاف پانی سے اچھی طرح دھو لیں اور پانی کے دھبوں کو روکنے کے لیے نرم کپڑے سے خشک کریں۔
عمومی دیکھ بھال:
- لیک کو روکنے کے لیے وقتاً فوقتاً تمام کنکشنز کو سختی کے لیے چیک کریں۔
- If water flow decreases, check for blockages in the shower heads or filters.
خرابی کا سراغ لگانا
This section addresses common issues you might encounter with your shower column.
| مسئلہ | ممکنہ وجہ | حل |
|---|---|---|
| کم پانی کا دباؤ | Partially closed water supply valve; clogged shower head nozzles; mineral buildup in internal components. | Ensure water supply valves are fully open. Clean shower head nozzles by rubbing the rubber tips. If problem persists, consult a plumber. |
| کنکشن سے پانی کا اخراج | Loose connections; worn seals or O-rings. | Tighten connections with an adjustable wrench (do not overtighten). If leaks persist, replace seals or O-rings. Ensure PTFE tape was used during installation. |
| پانی کا درجہ حرارت متضاد | Issues with water heater; unbalanced hot/cold water pressure. | Check your water heater settings. Ensure consistent water pressure from both hot and cold lines. |
| Function selector knob is stiff or not switching | معدنی تعمیر؛ اندرونی میکانزم کا مسئلہ | Apply a silicone-based lubricant to the knob base. If the issue persists, professional service may be required. |
وضاحتیں
| وصف | تفصیل |
|---|---|
| برانڈ | احساس |
| ماڈل نمبر | 3276000332329 |
| طول و عرض (L x W x H) | 48 x 21 x 145 سینٹی میٹر |
| وزن | 8.2 کلوگرام |
| مواد | Aluminum, Metal, Stainless Steel, ABS |
| ختم کرنا | کروم |
| تنصیب کا طریقہ | وال ماؤنٹ |
| ہینڈلز کی تعداد۔ | 1 |
| ASIN | B08THKTZ2G |
وارنٹی اور سپورٹ
Information regarding product warranty and customer support is not available in the provided product data. Please refer to the product packaging or contact the retailer/manufacturer directly for details on warranty coverage and support services.
