Beko DIN34320 Fully Built-in Dishwasher User Manual

1. تعارف

Thank you for choosing a Beko appliance. This user manual provides essential information for the safe and efficient operation, installation, and maintenance of your Beko DIN34320 fully built-in dishwasher. Please read these instructions carefully before using your appliance to ensure optimal performance and to prevent any damage or injury.

The Beko DIN34320 is a fully integrated dishwasher designed for seamless installation into your kitchen cabinetry, offering a capacity of 13 place settings and an energy efficiency class E.

2. حفاظتی معلومات

آگ، برقی جھٹکا، اور افراد کو چوٹ لگنے کے خطرے کو کم کرنے کے لیے برقی آلات کا استعمال کرتے وقت ہمیشہ بنیادی حفاظتی احتیاطی تدابیر پر عمل کریں۔

• ڈش واشر استعمال کرنے سے پہلے تمام ہدایات پڑھیں۔
• یہ آلہ صرف گھریلو استعمال کے لیے ہے۔
• بچوں کو ڈش واشر کے ساتھ، پر یا اندر کھیلنے کی اجازت نہ دیں۔
• یقینی بنائیں کہ ڈش واشر مناسب طریقے سے گراؤنڈ ہے۔
• ڈش واشر کو نہ چلائیں اگر اس میں بجلی کی ہڈی یا پلگ خراب ہو۔
• Keep detergents and rinse aid out of the reach of children.
• صرف ڈٹرجنٹ استعمال کریں اور خاص طور پر ڈش واشرز کے لیے بنائے گئے ایڈز کو کللا کریں۔
• Sharp items should be loaded with handles up to prevent cuts.
• آپریشن کے دوران دروازہ نہ کھولیں، کیونکہ گرم پانی نکل سکتا ہے۔

3. سیٹ اپ اور انسٹالیشن

آپ کے ڈش واشر کی کارکردگی اور لمبی عمر کے لیے مناسب تنصیب بہت ضروری ہے۔ یہ سفارش کی جاتی ہے کہ تنصیب کو ایک قابل ٹیکنیشن کے ذریعہ انجام دیا جائے۔

3.1 پیک کھولنا

Carefully remove all packaging materials. Inspect the dishwasher for any damage that may have occurred during transit. Report any damage to your retailer immediately.

3.2 Positioning and Dimensions

Your Beko DIN34320 is a fully built-in model, designed to be integrated into a standard kitchen cabinet. Ensure the cabinet dimensions match the appliance requirements.

شکل 1: سامنے view of the Beko DIN34320 dishwasher, illustrating its design for full integration into kitchen cabinetry.

• اونچائی: 82 سینٹی میٹر
• چوڑائی: 60 سینٹی میٹر
• گہرائی: 55 سینٹی میٹر

Ensure there is adequate space for water inlet and outlet hoses, and the electrical cable.

3.3 پانی کا کنکشن

Connect the water inlet hose to a cold water supply with a minimum pressure of 0.03 MPa and a maximum of 1 MPa. The water outlet hose should be connected to a drain pipe, ensuring it is not kinked or obstructed.

3.4 الیکٹریکل کنکشن

Connect the dishwasher to a grounded electrical outlet. The appliance operates on 230 Volts. Ensure the electrical supply meets the specifications of the appliance and local regulations.

3.5 Cabinet Door Installation

As a fully integrated model, a custom cabinet door panel must be attached to the front of the dishwasher. Follow the detailed instructions provided in the separate installation template for precise alignment and secure fastening of the panel.

4. آپریٹنگ ہدایات

This section guides you through the daily use of your Beko DIN34320 dishwasher.

4.1 کنٹرول پینل ختمview

The Beko DIN34320 features a fully integrated control panel, typically located on the top edge of the dishwasher door. Controls are visible only when the door is open and include program selection buttons, a start/pause button, and an LED display for program status and remaining time.

4.2 ڈش واشر لوڈ کرنا

For optimal cleaning results, load dishes correctly. Scrape off large food particles before loading. Place larger items in the lower basket and delicate items like glasses in the upper basket.

شکل 2: داخلہ view of the dishwasher, showing the arrangement of the upper and lower baskets, and the cutlery basket.

شکل 3: سابقample of a loaded dishwasher, illustrating how to arrange various dishes for effective cleaning.

• یقینی بنائیں کہ سپرے بازو آزادانہ طور پر گھوم سکتے ہیں۔
• Place cups, glasses, and small bowls upside down in the upper basket.
• Place plates, larger bowls, and pots in the lower basket.
• Use the cutlery basket for forks, spoons, and knives, placing sharp ends down.

4.3 ڈٹرجنٹ اور کلین ایڈ شامل کرنا

Open the detergent dispenser and add the recommended amount of dishwasher detergent. Close the dispenser lid securely. Check the rinse aid indicator and refill if necessary.

4.4 پروگرام کا انتخاب کرنا

Your dishwasher offers several wash programs to suit different needs. Common programs include:

• ایکو پروگرام: Energy-efficient program for normally soiled dishes. (Water consumption: 12.9 L, Duration: 3:25 h:min)
• خودکار پروگرام: مٹی کی سطح کی بنیاد پر واش سائیکل کو خودکار طور پر ایڈجسٹ کرتا ہے۔
• Other optional cycles are available for specific washing needs.

Refer to the control panel for specific program options and their indicators.

4.5 پروگرام شروع کرنا

Close the dishwasher door firmly. Select your desired program using the program selection buttons. Press the Start/Pause button to begin the cycle. The LED display will show the program status.

4.6 پروگرام ختم کرنا

Once the program is complete, the dishwasher will signal with an audible alert or a light indicator. Carefully open the door and allow dishes to cool before unloading. Unload the lower basket first to prevent water from dripping onto dry dishes.

5. دیکھ بھال اور دیکھ بھال

باقاعدگی سے دیکھ بھال اس بات کو یقینی بناتی ہے کہ آپ کا ڈش واشر مؤثر طریقے سے چلتا ہے اور اس کی عمر بڑھ جاتی ہے۔

5.1 صفائی کے فلٹرز

The filter system prevents large food particles from entering the pump. Clean the filters regularly (at least once a week) to ensure optimal washing performance. Remove the lower basket, twist and lift out the filter assembly, rinse under running water, and reassemble.

5.2 اسپرے بازوؤں کی صفائی

Check the spray arm nozzles for blockages. If necessary, remove the spray arms and clean the holes with a thin object like a toothpick. Rinse thoroughly and reattach.

5.3 اندرونی اور بیرونی صفائی

اشتہار کے ساتھ اندرونی حصے کو صاف کریں۔amp cloth after each use. For the exterior, use a soft, damp کپڑا اور ہلکا صابن. کھرچنے والے کلینر سے پرہیز کریں۔

5.4 Adding Dishwasher Salt

If your water supply is hard, you may need to add dishwasher salt to the dedicated salt dispenser to prevent limescale buildup. The salt indicator light on the control panel will illuminate when a refill is needed.

6 خرابیوں کا سراغ لگانا

سروس سے رابطہ کرنے سے پہلے، درج ذیل عام مسائل کو چیک کریں:

If the problem persists after checking these points, please contact Beko customer support.

7. وضاحتیں

Detailed technical specifications for the Beko DIN34320 dishwasher.

7.1 Energy Label and Product Information Sheet

The energy label provides key information about the appliance's energy consumption and performance. The product information sheet offers more detailed specifications.

Figure 4: EU Energy Label for the Beko DIN34320 dishwasher.

For detailed product information, including the official product information sheet, please visit the EPREL database:

https://eprel.ec.europa.eu/qr/267641

Figure 5: Product Information Sheet (example in French, content is consistent across languages).

8. وارنٹی اور سپورٹ

8.1 وارنٹی کی معلومات

This Beko dishwasher comes with a minimum warranty period of 24 ماہ provided by the supplier. Please retain your proof of purchase for warranty claims.

8.2 کسٹمر سپورٹ

For technical assistance, spare parts, or warranty service, please contact the authorized service provider:

• خدمات مہیا کرنے والا: Arctic Epel Support
• ای میل: Eprel_support@arctic.ro
• فون: 0245605111
• Webسائٹ: https://www.beko.ro
• پتہ: 13 DECEMBRIE, 210 135200 Gaesti Romania
