NEEWER Adjustable Sling Handle Grip for DJI Ronin Gimbals (Model ST49) Instruction Manual

تعارف

This instruction manual provides detailed information on the NEEWER Adjustable Sling Handle Grip, Model ST49. This accessory is designed to enhance the handling and versatility of your DJI Ronin gimbal stabilizer, offering improved comfort and control for various shooting scenarios, particularly low-angle shots.

Figure 1: NEEWER Adjustable Sling Handle Grip mounted on a DJI Ronin gimbal.

پروڈکٹ ختمview

The NEEWER Adjustable Sling Handle Grip (Model ST49) is constructed from durable aluminum alloy with a comfortable silicone-coated handgrip. It features a quick-release NATO clamp for secure attachment and multiple expansion options for accessories.

شکل 2: تفصیلی پروڈکٹ ختمview highlighting key components and mounting points.

• Silicone Coated Handgrip: Provides a non-slip and comfortable hold.
• Quick-Release NATO Clamp: For fast and secure attachment to compatible gimbals, with a load capacity of up to 13.2 lb (6 kg). Includes a locking button and spring bolt to prevent accidental loosening.
• 180° Rosette Joint: Allows for flexible angle adjustment, tilting 180 degrees up and down, enabling diverse shooting angles. The rosette joint can be separated for use as a side grip.
• Multiple Expansion Options: Equipped with 1/4 inch and 3/8 inch threaded holes, ARRI pin mounting holes, and two cold shoe adapters for attaching various accessories such as monitors, LED video lights, and sound receivers.

مطابقت

The NEEWER Adjustable Sling Handle Grip (Model ST49) is compatible with the following DJI Ronin gimbal stabilizers:

• DJI Ronin RS4
• DJI Ronin RS4 Pro
• DJI Ronin RS3 Mini
• DJI Ronin RS3 Pro
• DJI Ronin RS3
• DJI Ronin RS2
• DJI Ronin RSC2

Figure 3: Visual representation of the handle's compatibility with different DJI Ronin gimbal models.

سیٹ اپ اور انسٹالیشن

Follow these steps to securely attach the sling handle grip to your compatible DJI Ronin gimbal:

1. ماؤنٹنگ پوائنٹ کی شناخت کریں: Locate the NATO rail on your DJI Ronin gimbal. The sling handle attaches to this rail.
2. Attach NATO Clamp: Align the quick-release NATO clamp of the sling handle with the NATO rail on your gimbal. Slide the clamp ریل پر.
3. Cl کو محفوظ کریں۔amp: Once positioned, tighten the locking knob on the NATO clamp until it is firm and secure. Ensure the spring bolt engages to prevent accidental detachment.
4. ہینڈل زاویہ کو ایڈجسٹ کریں: Loosen the rosette joint knob on the handle to adjust the angle to your desired position. Once set, tighten the knob firmly to lock the angle.

ویڈیو 1: پروڈکٹ اوورview demonstrating the attachment and adjustment of the sling handle.

Video 2: Demonstration of attaching the NEEWER Gimbal Sling Handgrip to a DJI RS 2.

آپریٹنگ ہدایات

The sling handle grip is designed to improve your gimbal operating experience. Here are some common uses:

• کم زاویہ کی شوٹنگ: Adjust the handle to a lower position using the 180° rosette joint to comfortably capture shots from a low perspective. This reduces arm fatigue during extended use.


شکل 4: سابقamples of low-angle shooting facilitated by the sling handle.

• Access to Gimbal Controls: The handle features a cut-out design to ensure full access to gimbal mode switches and other controls on the right side of the gimbal.


Figure 5: The handle's design allows unobstructed access to gimbal controls.

• لوازمات کی تنصیب: Utilize the multiple 1/4" and 3/8" threaded holes and cold shoe mounts to attach external monitors, microphones, LED lights, or other necessary accessories to your setup.


Figure 6: The handle provides ample mounting points for additional accessories.

دیکھ بھال

To ensure the longevity and optimal performance of your NEEWER Adjustable Sling Handle Grip, follow these maintenance guidelines:

• صفائی: Wipe the handle with a soft, dry cloth after each use to remove dust and debris. For stubborn dirt, use a slightly damp کپڑا اور ہلکا صابن، پھر اچھی طرح خشک. سخت کیمیکلز سے پرہیز کریں۔
• ذخیرہ: Store the handle in a dry, cool place away from direct sunlight and extreme temperatures. Its foldable design allows for compact storage.


Figure 7: The handle's foldable design makes it easy to store and transport.

• معائنہ: Periodically check all screws, knobs, and joints for tightness. Re-tighten if necessary to maintain stability and prevent accidental loosening.

خرابی کا سراغ لگانا

If you encounter any issues with your sling handle grip, refer to the following common troubleshooting tips:

• Handle feels loose after attachment:
  • نیٹو cl کو یقینی بنائیںamp's locking knob is fully tightened.
  • Verify that the spring bolt on the connector is properly engaged.
  • Check if the rosette joint knob is securely tightened after angle adjustment.
• Accessories not mounting securely:
  • Confirm that the accessory's mounting screw (1/4" or 3/8") matches the threaded hole on the handle.
  • For cold shoe accessories, ensure they are fully inserted and locked into place.

وضاحتیں

Figure 8: Dimensions and detailed specifications of the sling handle.

پیکیج کے مشمولات

• 1 x Sling Handgrip

وارنٹی اور سپورٹ

For warranty information, technical support, or customer service inquiries, please refer to the official NEEWER webسائٹ یا اپنے خوردہ فروش سے رابطہ کریں۔ وارنٹی کے دعووں کے لیے اپنی خریداری کی رسید اپنے پاس رکھیں۔
