Bosch Professional GFA 18-WM FlexiClick Angle Adapter Instruction Manual

1. تعارف

The Bosch Professional GFA 18-WM FlexiClick Angle Adapter is a versatile accessory designed to enhance the functionality of your Bosch Professional GSR 18V-90 FC screwdriver. This adapter allows for precise drilling and screwing applications in confined or hard-to-reach spaces, converting your screwdriver into an angle drill with a robust metal chuck. It features 16 adjustable positions and 360° rotation for optimal flexibility.

2. حفاظتی ہدایات

Always observe the following safety precautions when using the GFA 18-WM angle adapter:

• Read the Screwdriver Manual: Before using this adapter, thoroughly read and understand the instruction manual for your Bosch Professional GSR 18V-90 FC screwdriver.
• ذاتی حفاظتی سامان: Always wear appropriate personal protective equipment, including safety glasses, hearing protection, and gloves, when operating power tools.
• محفوظ اٹیچمنٹ: Ensure the angle adapter is securely attached to the screwdriver and the drill bit/screwdriver bit is firmly seated in the chuck before operation.
• ورک پیس استحکام: Always secure your workpiece to prevent movement during drilling or screwing.
• اوورلوڈنگ سے بچیں: Do not apply excessive force to the tool or adapter, as this can lead to damage or injury.
• استعمال سے پہلے معائنہ کریں: Before each use, inspect the adapter for any signs of damage or wear. Do not use if damaged.

3. پروڈکٹ ختمview

The GFA 18-WM is part of the Bosch Professional FlexiClick system, designed for modular versatility.

This image displays the Bosch Professional FlexiClick system, showcasing the GFA 18-WM angle adapter alongside other interchangeable attachments and a compatible drill driver. The GFA 18-WM is visible as the angular attachment with a metal chuck, demonstrating its role within the versatile system.

The GFA 18-WM angle adapter features a robust metal chuck for secure bit retention and a mechanism for adjusting its angular position relative to the screwdriver body.

4. سیٹ اپ اور انسٹالیشن

Follow these steps to attach the GFA 18-WM angle adapter to your Bosch Professional GSR 18V-90 FC screwdriver:

1. Prepare the Screwdriver: Ensure your GSR 18V-90 FC screwdriver is switched off and the battery is removed for safety.
2. Align the Adapter: Align the GFA 18-WM angle adapter with the FlexiClick interface on the front of your screwdriver. The adapter has a specific keyway that must match the screwdriver's receiver.
3. پش اینڈ ٹوئسٹ: Push the adapter onto the screwdriver until it clicks into place. Then, twist the adapter clockwise until it locks securely. You should hear and feel a distinct click, indicating it is properly engaged.
4. سیکیورٹی کی تصدیق کریں: Gently pull on the adapter to ensure it is firmly attached and does not wobble.
5. بٹ داخل کریں: Open the metal chuck by rotating the chuck collar counter-clockwise. Insert your desired drill bit or screwdriver bit into the chuck. Tighten the chuck by rotating the collar clockwise until the bit is securely held.

To remove the adapter, reverse the twisting motion and pull it off the screwdriver.

5. آپریٹنگ ہدایات

The GFA 18-WM angle adapter provides flexibility for various applications:

• زاویہ کو ایڈجسٹ کرنا: The adapter can be rotated 360° and locked into 16 different positions. To adjust the angle, grasp the adapter firmly and rotate it to the desired position. It will click into place at each of the 16 predefined angles. Ensure it is securely locked before beginning work.
• درخواست: Use the angle adapter for drilling or driving screws in tight corners, between studs, or in other confined spaces where a straight drill/driver cannot reach.
• Speed and Torque: Adjust the speed and torque settings on your GSR 18V-90 FC screwdriver according to the material and the task at hand. Start with lower speeds for greater control, especially when drilling or driving into delicate materials.
• کنٹرول برقرار رکھنا: Always maintain a firm grip on the screwdriver and adapter. Apply steady, even pressure.

6 دیکھ بھال

Proper maintenance ensures the longevity and performance of your GFA 18-WM angle adapter:

• صفائی: After each use, wipe down the adapter with a clean, dry cloth to remove dust, debris, and grime. Do not use harsh chemicals or solvents.
• چکنا: The internal mechanisms are factory-lubricated. Do not attempt to lubricate the adapter yourself unless specifically instructed by Bosch Professional.
• ذخیرہ: اڈاپٹر کو صاف، خشک جگہ، براہ راست سورج کی روشنی اور انتہائی درجہ حرارت سے دور رکھیں۔
• معائنہ: Regularly inspect the chuck for wear and tear. Ensure the locking mechanism for angular adjustment functions smoothly. If any damage is observed, discontinue use and contact Bosch Professional service.

7 خرابیوں کا سراغ لگانا

If you encounter issues with your GFA 18-WM angle adapter, consider the following:

• Adapter Not Attaching Securely:
  • Ensure the FlexiClick interface on both the screwdriver and adapter are clean and free of debris.
  • Verify correct alignment before pushing and twisting.
  • Check for any visible damage to the locking mechanism on either the adapter or the screwdriver.
• چک میں بٹ پھسلنا:
  • Ensure the chuck is tightened sufficiently.
  • Check if the bit shank is clean and free of oil or grease.
  • Inspect the chuck jaws for wear or damage.
• Difficulty Adjusting Angle:
  • Ensure no debris is obstructing the rotation mechanism.
  • Apply firm, even pressure when rotating.

For persistent issues, contact Bosch Professional customer support.

8. وضاحتیں

9. وارنٹی اور سپورٹ

For information regarding warranty coverage, service, or technical support for your Bosch Professional GFA 18-WM FlexiClick Angle Adapter, please refer to the documentation provided with your Bosch Professional power tool or visit the official Bosch Professional webسائٹ وارنٹی کے دعووں کے لیے اپنی خریداری کا ثبوت رکھیں۔
